Dental Waxes

In addition to our jewelry waxes and our pattern waxes, Freeman now manufactures the Kinco line of dental waxes, many of which are also used by jewelry manufacturers in various applications.

KINKO Inlay Waxes Inlay Waxes
Inlay Waxes are most often used for the construction of dental crowns and bridgework, but the unique properties are also coveting by many jewelry manufacturers. The exceptional durability of these waxes enables them to be cast in extremely thin sections and yet resist deformation from repeated handling.

Inlay Waxes can be easily carved and will burn-out cleanly with no residue. Available in three hardness grades.

Formula Hardness Standard Color(s)
1422N Regular Green, Blue
1501G Hard Green, Blue
1422B Extra Hard Purple

Availability: 1.5 oz. tins, 1/4” diameter x 5” long (6.35 mm x 127 mm) sticks in 3 ounce (84 gram) boxes, or 1 lb slabs.

Technical Data Sheet


KINCO Pink Baseplate Wax Pink Baseplate Wax
A recognized standard in the industry, Pink Baseplate Wax is a blend of fine virgin waxes that can be easily carved, will soften uniformly and will retain a shape when cold. This unusually strong, highly flexible wax will also withstand more bending without cracking or breaking than similar products. Clean burn-out qualities make Pink Baseplate Wax ideal for try-ins as well as a wide variety of general purpose products.

Available in two sheet sizes: .050” x 3” x 6” (1.27 x 76.2 x 152.4 mm) and .065” x 3” x 6” (1.65 x 76.2 x 152.4 mm)

Technical Data Sheet Safety Data Sheet

KINCO Pink Bite Wax Sticks Pink Bite Wax Sticks
Formulated from the highest quality waxes, Pink Bite Wax Sticks are easily shaped to conform to the dental arch and assure clean, accurate bite registration. Pink Bite Sticks are available in a standard square shape or our special square shape which features a concave surface.

Availability: 7/16” x 12” long (11.1 mm x 304.8 mm)

Technical Data Sheet

KINCO Red Boxing Wax Strips Red Boxing Wax Strips

Red Boxing Wax Strips are soft, tacky strips specially formulated for boxing-in impressions. The strips readily adhere to themselves or virtually any surface without the need for heat. Red Boxing Wax Strips are often used in conjunction with Utility Wax Ropes, which are positioned below the peripheral border of the impression.

Regular Size: 1/16” thick x 1-1/2” wide x 12” long (1.59 x 38.1 x 304.8 mm)
Thin Size: .040” thick x 1-1/2’ wide x 12” long (1.02 x 38.1 x 304.8 mm)

Technical Data Sheet Safety Data Sheet



Set-Up Wax
Set-up Wax was formulated for fixturing and molding of both set-up and try-ins in dentistry. Once warmed, this high purity wax features a long working time. However, once set, it is tenacious and tough enough to retain its shape.

Availability: Sheets .065” x 3” x 6” (1.65 x 76.2 x 152.4 mm)

Technical Data Sheet
